1GC.25B Garden Compact Tractor Loader Backhoe
Tractor & Implement Features
Available Attachments (Refer to Implement Section)
- MF 2315, 2320, 2326 Mid-Mounted Mowers: (Backhoe must be removed to operate mid-mount mower)
- MF SBx1270: Front-Mounted Snow Blower
- MF RBx1524: Front-Mounted Rotary Broom
- MF FBx1574: Front-Mounted Blade
Power Train
-
Engine: 24.5 Gross HP, 3-Cyl Diesel
- 1.12 L Displacement
- 23.6 Net HP @ 3000 RPM
- 18.5 PTO HP @ 3000 RPM
- Air Cleaner: Dry Type Single
- Transmission: 2-Range Hydrostatic with Cruise Control
- Brakes: Wet Disk
- Parking Brake: Standard
- Differential Lock: Standard
- PTO: 540 RPM Independent PTO / 2000 RPM Mid-Independent PTO
Hydraulic System
- 3-Point Hitch: Cat I with Directional Control, Auto-Return Lever System
- Pump: Engine-Driven Gear Pump
- 3-Point Hitch Flow: 4.9 GPM (18.8 LPM)
- Power Steering Flow: 2.0 GPM (7.5 LPM)
- Total Combined Flow: 6.9 GPM (26.3 LPM)
MF BH2720 Backhoe
- Digging Depth: 76 inches (1.9 m)
- Max Reach: 107 inches (2.7 m)
- Transport Height: 71 inches (1.8 m)
- Stabilizer Spread (Transport): 51 inches (1.3 m)
- Stabilizer Spread (Operating): 81 inches (2.1 m)
- Loading Height: 66 inches (1.7 m)
- Angle of Departure: 22 Degrees
- Swing Arc: 150 Degrees
- Bucket Rotation: 177 Degrees
- Shipping Weight: 573 lbs (260 kg)
- Digging Force (Bucket Cylinder): 2184 lbs (911 kg)
- Digging Force (Dipper Cylinder): 1541 lbs (699 kg)
- Swing Cylinder: Single Boom
- Note: Dimensions may change due to tire size. Backhoe must be detached before installing mid-mount mower.
FL.1805 Loader
- Frame: One-Piece Main Frame with Tapered Arms and Single Cross Member
- Mounting: Quick-Attach Loader Frame Mount with Pin Lock
- Parking: Built-in Parking Stands
- Cylinders: (2) 1.57-inch Double-Acting Lift / (2) 1.57-inch Double-Acting Bucket
- Operation: Simultaneous Lift/Lower and Curl/Dump Functions
- Hydraulic Lines: Routed inside Main Frame for protection and visibility
- Maintenance: Galvanized Pins with Recessed Grease Points
- Bucket: 48-inch Standard Duty Skid Steer Bucket
- Grille Guard: Standard
- Max Lift Height (Pivot Pins): 74 Inches
- Lift Capacity (Full Height at Pivot Pins): 922 lbs
- Lift Capacity (19.5" Forward of Pins): 622 lbs
- Breakout Force (Pivot Pins): 1,392 lbs
- Rated Hydraulic Pressure: 1,920 PSI
Instruments & Other Features
- Instruments: Tachometer / Hourmeter, Digital Fuel and Water Temp Gauges
- Warning Lights: Electrical Charging, Oil Pressure, Water Temperature
- Steering: Hydrostatic Power Steering with Tilt Column
- Operator Station: Side-by-Side Forward and Reverse Pedals, Hand Accelerator, Rubber Floor Mat, Covered Storage with 12V Socket
- Seat: Fully Adjustable Swivel Seat with Armrests and Retractable Seatbelt
- Safety: 2-Post Folding ROPS, Turn Signals, Flashers, Tail Lights
- Loader Control: Factory Joystick with Pressure and Return Line Manifold
- Battery: 390 Cold Cranking Amps
- Note: 3-Point Mounted Backhoe installation voids warranty. Use the required Subframe Mounting Kit.
