$3,699.00 USD
Pick up available
Usually ready in 48 hours
Patriot Tractor
Usually ready in 2-4 days
Description:
- Built to tackle big jobs while fitting in small spaces.
- Built Like a Bull - IronForged® high strength grade 50, 10-gauge steel deck with bull nose reinforced leading edge.
- Take control over your mowing speed, while never sacrificing blade tip speed.
- Step-Through Front End - Getting on and off the mower to pick up yard debris and other obstacles is a breeze with a step-through front end.
- Storage Cubby - Now there's a convenient and safe space in your under-seat cubby to store important items.
- Ride in style with a handcrafted seat that provides the ultimate in padding and back support.
- Commercial DNA courses through these machines' veins with the same technology pros depend on.
Specifications
| Air Filter | Standard Briggs & Stratton Air Cleaner |
|---|---|
| Anti Scalp Wheels | 2 Standard |
| Armrests | Optional |
| Bagger Capacity | 4.9 bushels |
| Blade Design | 0.164 in. / 0.417 cm Steel with Blade Stiffner |
| Blade Tip Speed | 18,179 ft/min / 5,541 m/min |
| Box Dimensions | 82.0 in. x 49.0 in. x 35.0 in. / 208.3 cm x 124.5 cm x 88.9 cm |
| CARB Compliant | Not CARB Compliant |
| Caster Tires | 11 in. x 4 in. - 5 in. Pneumatic |
| Clutch | Electromagnetic |
| Cooling System | Air Cooled |
| Crankshaft | 1" (25 mm) w/Steel Protector |
| Cup Holder | Standard |
| Cutter System | Steel Cutting Blade |
| Deck Design | 10-Gauge steel IrongForged® |
| Deck Material | 10 Gauge Steel |
| Deck Size | 34 in / 86 cm |
| Discharge Chute | Side |
| Drive System | HYDRO |
| Drive Tires | 18 in. x 6 in. - 8 in. (45.7 cm x 15.2 cm - 20.3 cm) |
| Drive Type | Rear-Wheel Drive |
| Engine | 22 hp Briggs and Stratton EXI 724cc |
| Engine Brand | Briggs and Stratton |
| Engine Displacement (cc) | 724 cc |
| Engine Horsepower | 22.0 hp |
| Engine Power (kW) | 16.4 kW |
| Foot Operated Height of Cut | Optional |
| Forward Ground/Transport Speed | Up to 7.0 mph / 11.2 kph |
| Forward Mowing Speed | Up to 7.0 mph / 11.2 kph |
| Fuel Capacity | 3 gal. / 11.4 L / 12 Qt. |
| Fuel Type | Gasoline |
| Greasable Bearings | Yes |
| Height of Cut | 1.5 - 4.5 in. / 3.8 - 11.4 cm |
| Hitch Bracket | Standard |
| Hour Meter | Optional |
| Hydraulic Dampeners | Yes, Non-Cavitating |
| Hydraulic Drive | Standard |
| Number of Blades | 2 |
| Product Type | TimeCutter |
| Product Use | Residential |
| Recommended Oil Type | 10W-30 |
| Roll-Over Protection System (ROPS) | Optional |
| Seat | 16" Handcrafted |
| Spindle Bearings | Maintenance-free |
| Spindle Housing | Cast-Aluminum |
| Start Type | Electric |
| Steering Controls | Dual Wrap Around Levers |
| Steering Dampeners | Standard Dampers |
| Terrain Type | Flat with Obstacles |
| Tow Capacity | Combined machine, user, towed weight may not exceed 1,000 lbs. |
| Transmission | Dual Hydrostatic HG-EZT2100 |
| Washout Port | Standard |
| Weight | 496 lbs / 225 kg |
Disclaimer
*22 HP gross at 3,600 RPM SAE J1940 and SAE J2723, as rated by Briggs & Stratton®. As configured to meet safety, emission and operating requirements, the actual engine horsepower on this mower may be significantly lower.†See retailer for complete warranty details.‡Specifications subject to change without notice and without incurring obligation. Products depicted are for demonstration purposes only. Actual products offered for sale may vary in design, required attachments and safety features.
